Solar water pumping system

Home / Solar water pumping system


The solar photovoltaic water pump system mainly consists of three parts: solar cell modules, photovoltaic water pumping inverters, and three-phase AC water pumps. A solar cell array is composed of multiple solar cell modules in series and parallel, which absorb sunlight radiation energy and convert it into electrical energy, providing power for the entire system. The photovoltaic water pumping inverter controls and regulates the operation of the system, converting direct current from the solar cell array into alternating current, driving the water pump, and adjusting the output frequency in real-time according to changes in sunlight intensity to achieve maximum power point tracking and maximize the utilization of solar energy. The water pump is driven by a three-phase AC motor, which draws water from a deep well and injects it into a storage tank/pool or directly connects to the irrigation system. According to actual system requirements and installation conditions, different types of water pumps can be used for operation. The system power ranges from 0.37kW to 55kW, the water lift can be between 10 meters to 300 meters, and the daily water lift can be between 3 tons to 1000 tons.


  • Water and electricity shortage areas
  • Deep water pumping
  • Drinking water wells.


  • Photovoltaic array

    A series of solar modules are connected in series and in parallel, which mainly convert the solar energy into electric energy and provide operating power to the load pump motor.

  • Water pump

    According to the actual system requirements and installation conditions, different types of pumps can be selected. The most commonly used is a submersible pump (deep well pump) to extract water from deep wells or rivers and lakes and inject the water into K pools or directly connect into irrigation systems.

  • DC pump system configuration

    Since the pump itself is an inductive load, it needs a slightly larger starting current, and it must be able to operate under weak sunlight. A pump controller can be used to provide a large instantaneous startup current under weak sunlight.

  • AC pump system configuration

    It controls and regulates solar pump operation, and converts the DC power generated by the PV array into AC power to drive the pump. The well adjusts the output frequency in real time according to the change of the sunshine intensity to achieve maximum power point tracking.


Optical, mechanical and electrical integration, simple installation and maintenance, low operating cost, efficient and safe, economical and practical. Deep well pumping can meet the needs of farmland irrigation or human and animal drinking, effectively solving the water supply problem in areas with water and electricity shortages. Photovoltaic power generation is noise free, environmentally friendly, and has a wide range of applications.
